Application:

The CNC gantry drilling and milling machine is mainly used for the drilling, chamfering, tapping, and milling of plate/structural parts with the thickness of flanges, discs, rings, plates and other workpieces within the effective range. Drilling through holes and blind holes can be realized on single material parts and composite materials. The processing process is digitally controlled and the operation is very convenient. It can realize automation, high precision, multiple varieties and mass production.

Equipment structure:
The equipment is integrally cast, mainly composed of worktable, fixed beam gantry, movable sliding saddle, drilling and milling power head, automatic lubrication device, protective device, circulating cooling device, digital control system, electrical system, etc. Rolling hard rail pair support and guidance, precision lead screw pair drive, the machine tool has high positioning accuracy and repeat positioning accuracy.

T-slot workbench:
The workbench is made of gray iron (HT250), which is finished by secondary tempering and vibration aging treatment, with good rigidity and no deformation.

Fixed beam type gantry:
The gantry is made of gray iron (HT250). The front side of the gantry is equipped with two ultra-high bearing capacity rolling linear guide pairs, a set of precision ball screws and a servo motor to make the power head slide plate move in the Y axis direction , drilling power head is installed on the power head slide plate. The gantry movement is realized by the rotation of the ball screw driven by the servo motor through the precision coupling.

Specifications:

Jinan Auten Machinery Co., Ltd. is a professional company dedicated in developing, studying, designing, manufacturing, and selling cnc machines, such as cnc angle punching machine line, cnc angle drilling machine line, cnc plate punching machine, cnc plate drilling machine, cnc H beam drilling machine, cnc beam band sawing machine, cnc plate roller forming machine, cnc pipe cutting machine, cnc plate plasma cutting machine, cnc grinding machine, electric power fittings and so on. Jinan Auten Machinery Co., Ltd. is affiliated with Jinan CNC Machine Group of Evershining. There are about 200 staffs, the company was established in 2003, the company’s annual turn over is about 15 million USD. The customers are world-widely distributed in many countries.

We have a great engineer team and owns so much more advanced technology for cold roll forming industry, steeltower industry and steel structure industry. Main business is metal forming machine, cnc angle processing machine, cnc H beam processing machine, cnc plate processing machine, cnc pipe processing machine, cnc cutting machine, cnc grinding machine, electric power fittings and so on.

The main feature of the company is serving best quality machines with reasonable price and best service after sales. Our company insists the product principle of "do the new ones, do the good ones " and the enterprise aim of "trustworthiness, cooperation, study, and innovation ". The company sets up the service principle of "to focus customer as work center", to satisfy customized request, with high-quality, trustworthiness service and continuous innovation to raise customer's satisfaction, to become the best cooperative colleague of the customers. Each step of the developments of the company all comes from the customer's trust and support, the company is always using the professional to create new brighter future together with customers all over the world.
